Beijing Youenmi Technology Co,.Ltd

Beijing Youenmi Technology  has been focusing on Research & Development of hi-tech temperature and gas sensors, further more, we handle with interrelated field subject development.  We make our mind to meet our customers great demands.Non-fixed temperature sensor，Application: Using protective stainless steel tube for encapsulation. The wires in the bottom are tightly pressed with rings, which excellent in resisting oil, water, shake and pressure. These sensors can be used in many areas, including medical instrument, intelligent instrument, gas, liquid, etc.Sensitive element: Pt 100, Pt200, Pt 500 or Pt 1000 (single or double)Tolerance: all conform to the requirements of IEC 751Temperature range: For low temperature type: -200℃--＋400℃For high temperature type: -50℃--＋550℃Shell: -- diameter: φ2.00 mm, length: 300 mm-- diameter: φ3.00 mm, length: 300 mm-- diameter: φ4.00 mm, length:400 mm-- diameter: φ5.00 mm, length:500 mmOther types can be customizedWires: 2, 3 and 4-wire or connector-- length: can be customized-- type: PTFE (Max. temperature 300℃)FEP (Max. temperature 250℃)Silica gel (Max. temperature 125℃)PVC (Max. temperature 105℃)Protective grade: all conform to the requirements of IP 54Option:-- Screening wire-- Protective grade—Ipxx-- Higher precision ( Glass A, DIN1/3，DIN1/10)-- Protective tube ,according to DGS,DGV-- Screwd wire-- Protective spring-- Connector
